Specialist Solar, Energy Storage & Microgrid Systems
Midrand, Johannesburg, South Africa | info@hv-commissioning.co.za
We are pleased to submit this professional proposal for the high-level commissioning, system validation, grid-synchronization testing, and safety handover of your installed MegaRevo systems. Our team brings specialized engineering expertise in commercial power conversion systems (PCS), lithium battery management communication (BMS), and utility grid compliance testing.
1. Technical Scope of Commissioning
All work will be performed under certified electrical engineering safety standards, complying with **IEC 62446** for physical PV array checks and DC insulation testing, and **IEEE 1547** for distributed energy resources grid interconnection and anti-islanding compliance.
2. Commissioning Cost Schedule
| Commissioning Work Item | Quantity / Rate | Total Amount |
|---|
3. Project Terms & Authorization
* Pricing is valid for 60 days. Commissioning will be scheduled upon receipt of signed contract. A 50% mobilization deposit is required, with the remaining 50% invoiced net-15 upon final commissioning report submittal. Access to reliable Internet/BMS network connections and battery manufacturer safety passwords are site owner responsibilities.
Engineering, Design & Municipal Compliance Planning
Midrand, Johannesburg, South Africa | info@hv-commissioning.co.za
This engineering report outlines the technical site design, structural planning, and electrical cable schedule for the proposed solar photovoltaic installation. All plans and specifications are prepared using high-fidelity **OpenSolar** layout models and conform strictly to South African SANS 10142-1 (Wiring Code of Practice) regulations.
1. OpenSolar Structural & Layout Checklist
The site layout has been modeled utilizing digital shading models to optimize solar yields. Visual layouts detail PV placement avoiding obstacles and maintaining physical clearance.
2. Cable Schedule & Voltage Drop Sizing
Cable diameters are sized specifically to limit voltage drop under peak generation loads. Keeping cable drops under 1.5% maximizes energy yields and prevents local overvoltage trip errors on the MegaRevo system.
| Electrical System Segment | Parameters (Current & Run) | Conductor Spec & Material | Calculated Drop (%) |
|---|---|---|---|
|
DC String Cabling (Roof Run) Solar PV module arrays to local DC recombiners / inverter cabinets. |
13.5 A peak over 45 meters | 4.0 mm² Copper PV Cable | 0.98% |
|
AC Power Cabling (Inverter DB) MegaRevo hybrid PCS AC outputs to site Main Distribution Board (DB). |
721.7 A peak over 65 meters | 2x 185 mm² Copper XLPE | 1.22% |
3. Municipal Switchgear & Breaker Coordination
The connection from the inverter to the council grid conforms to local municipal bylaws. Protection settings and disconnect switch parameters are coordinated with local utility grid engineers.
| Switchgear Component | Required Specifications & Standards | Requirement Status |
|---|---|---|
| Inverter Main Breaker | Standard 800 Amp, 3-Phase molded-case breaker (MCCB) | Mandatory |
| Main Disconnect Switch | Heavy-duty AC isolator switch (DVD/DVR) with mechanical padlocks | Mandatory |
| Surge Protection (SPD) | Type 1 + Type 2 DC and AC surge arrestors for grid and lightning protect | Mandatory |
| Municipal Smart Meter | Bidirectional 4-quadrant check meter with utility G59/IEEE 1547 interface | Mandatory |
